A servo axis that suddenly faults, hunts at standstill or loses position can stop far more than one motor. On a packaging line, conveyor transfer, mill or automated cell, the result may be damaged product, lost production time and a difficult restart. Effective servo drive troubleshooting is therefore not a matter of replacing the drive that displays an alarm. It is a controlled process of separating supply, drive, motor, feedback, mechanical and control-system faults.
Servo systems operate with high DC bus voltages, stored energy and moving machinery. Only suitably qualified personnel should test or adjust the equipment, following site isolation procedures, the manufacturer’s instructions and the machine risk assessment. A fault reset is not a repair if the underlying condition remains.
Start servo drive troubleshooting with the fault record
The alarm code is the best starting point, but it is only one part of the evidence. Before cycling power, record the drive model, firmware version where available, displayed fault code, axis status, PLC or motion-controller messages, operating mode and the point in the machine cycle when the trip occurred. Note whether the fault is repeatable, intermittent, load-related or tied to a particular product, speed or environmental condition.
This record matters because a servo drive may report an overcurrent fault when the actual cause is a jammed mechanism, poor motor cable termination, incorrect motor data or an aggressive acceleration setting. Likewise, a following error may originate in encoder feedback, mechanical backlash, a slipping coupling or an axis that cannot produce the required torque.
Review recent changes before changing parameters. A replacement motor, new cable route, software revision, gearbox repair, altered payload or electrical work near the machine can all create a problem that appears to be a drive fault. In maintenance work, the timing of the failure often narrows the investigation faster than the alarm text alone.
Confirm power quality and drive status
With the equipment isolated and made safe as required, inspect the incoming supply, protection devices, earthing arrangement, cabinet ventilation and drive terminals. Look for loose connections, overheated conductors, discolouration, contamination, moisture ingress and damaged shielding. A drive can operate normally during a brief no-load test yet fail once current demand and cabinet temperature rise.
After safe energisation and with appropriate test methods, verify that supply voltage is within the drive specification and balanced across phases where applicable. Investigate voltage dips during simultaneous motor starts, welding activity, weak generator supply or switching of large loads. Undervoltage trips can be intermittent and may occur only at a specific stage of production.
Overvoltage events need a different line of enquiry. During deceleration, the motor returns energy to the DC bus. If the machine has high inertia, a rapid deceleration profile or inadequate regenerative capacity, the bus voltage can rise beyond the drive limit. Check deceleration time, actual load inertia, braking resistor specification and the condition of associated wiring. Extending the deceleration time may remove the trip, but it is not always acceptable where machine throughput or safety stopping requirements dictate the stopping profile.
Also confirm the drive enable circuit, safety functions and external interlocks. A missing enable signal, active safety torque off circuit or unresolved fieldbus communication fault can look like an axis failure, even when the drive, motor and feedback hardware are healthy.
Separate motor, cable and feedback faults
A reliable way to avoid unnecessary drive replacement is to inspect the complete axis as a system. Start with the motor power cable and feedback cable. Servo feedback is low-level, high-speed signalling and is vulnerable to poor connector engagement, damaged pins, contaminated plugs and electrical noise. Ensure feedback and motor cables are correctly terminated, shielded as specified by the manufacturer and separated from high-current power conductors where the installation requires it.
Do not use insulation-resistance testing on a motor while it remains connected to the servo drive. Test procedures must follow the motor and drive manufacturer’s requirements. A conventional insulation tester connected incorrectly can damage sensitive drive output stages or feedback electronics.
Where the system permits, compare fault behaviour across identical axes. Swapping only approved, compatible components in a controlled manner can help isolate whether a fault follows the motor, cable or drive. This should be planned carefully, with parameter backups and motor compatibility checked first. A motor with different encoder type, brake characteristics or rated current must not be connected simply as a quick test.
Common physical causes include a fractured cable conductor that fails only when the axis moves, coolant entering a connector, a brake that does not release fully, or a coupling that has loosened on the motor shaft. These faults may produce inconsistent alarms, particularly where vibration and heat are involved.
When position errors are mechanical
Following error, position deviation and excessive torque alarms deserve a mechanical inspection as well as an electrical one. Check for seized bearings, worn ballscrews, belt tension issues, damaged gearboxes, misalignment, poor lubrication and obstructions in the travel path. Examine couplings, keys and clamping elements for movement or wear.
A machine can be mechanically functional but still unsuitable for its existing servo tuning. Higher product weight, altered tooling, a rebuilt transmission or changed machine stiffness can reduce stability margins. If oscillation, vibration or hunting began after a mechanical modification, review tuning only after the mechanism has been confirmed sound. Increasing gain to force a response can worsen instability and place extra load on the motor and transmission.
Check parameters before changing them
Parameter errors frequently arise after drive replacement, controller replacement or an incomplete commissioning backup. Confirm the motor model, encoder resolution, feedback direction, electronic gearing, travel limits, torque limits, current limits and brake control settings. The drive and controller must use a compatible configuration for the installed motor and application.
Before any edits, save the existing parameter set and document the reason for each change. This gives maintenance teams a known recovery point if a trial adjustment produces an unexpected result. It also prevents gradual, undocumented changes from becoming the accepted machine standard.
Tuning should be approached as an engineering task, not an alarm-clearing exercise. Observe commanded position or speed, actual feedback, torque demand, following error and fault history over a normal operating cycle. A high torque demand on acceleration suggests a load, inertia or profile issue. A noisy or unstable feedback trace may point to encoder, cabling, shielding or tuning concerns. The correct response depends on what the data shows.
A practical fault-isolation sequence
For recurring faults, use a consistent sequence rather than working from the most convenient component.
1. Make the machine safe, capture fault codes and record the conditions at the time of the trip.
2. Check supply quality, earthing, drive status, safety circuits and control communications.
3. Inspect motor power, feedback and brake wiring, including connectors and cable routing.
4. Assess the mechanical load for binding, backlash, misalignment, overload and changes to inertia.
5. Verify motor data, motion parameters and tuning against the approved machine configuration.
6. Test under controlled operating conditions and compare traces or behaviour with a healthy axis where possible.
This order reduces the risk of masking a mechanical or installation fault with a parameter change. It also creates a useful maintenance record for intermittent issues that may not be present during a short shutdown window.
Know when the drive is the likely cause
A servo drive becomes a stronger suspect after supply conditions, cabling, motor insulation and feedback integrity have been checked, and the fault remains associated with that drive channel. Visible component damage, persistent internal hardware alarms, failed self-tests or repeated faults that follow the drive after approved substitution are further indicators.
Even then, replacement should be considered in the context of the application. An obsolete drive may require a planned migration involving motor compatibility, controller communications, safety architecture and parameter conversion. A direct replacement is usually lower risk for urgent recovery, while an upgrade can be the better commercial option where spares availability, performance or lifecycle support are concerns.
For critical plant, hold a verified configuration backup and maintain clear records of motor part numbers, cables, feedback types and commissioned settings. Tech Source can assist with specifying compatible automation and motion-control components when a replacement, upgrade or application review is required.
The fastest repair is usually the one that proves the cause before parts are ordered. Treat each servo fault as evidence from a complete motion system, and the resulting fix is more likely to survive the next production run.
